P4.81 户外全彩-250X250mm-13S--租赁款--铝箱--

1

Pixel pitch

4.81mm

2

Pixel configuration

1R1G1B

3

LED encapsulation

SMD1921

4

Brand of LED lights

MLS/KINGLTGHT/NATIONSTAR

5

Module resolution

52dots *52dots

6

Module pixel

2704dots

7

Module size

250mm*250mm

Cabinet Parameters

8

Cabinet size

(L*H)500mm*500mm/500mm*1000mm

9

Material

Die-casting aluminum or Iron

10

Weight

About 8kg or 13Kg /pcs

11

Area

0.25or 0.5m²/pcs

12

Cabinet resolution

192dots * 192dots

13

Average power consumption

450W/ m²～600W/ m²

14

Max. power consumption

≤1200W/ m²

15

Working Voltage

AC110 / AC220V±10%  50～60HZ

16

Brightness

4000cd~5200cd/ m²

17

Brightness Adjustment

Manual & Automatically

18

Gray scale

15 bit

19

Drive IC

5020 IC or High refresh IC

20

Driving method

1/13 scan, constant current

21

Refresh frequency

≥1920Hz

22

Frame frequency

≥60Hz

Screen Parameters

23

Pixel density

43264dots/m²

24

Viewing distance

3m～60m

25

Viewing angle (H/V)

Horizontal 140° Vertical 120°

26

Life span

≥100,000h

27

MTBF

≥10,000h

28

Working temperature & humidity

﹣20℃ ~ 65℃, 20％ to 90％

29

Storage temperature & humidity

﹣40℃ ~ 85℃, 10％ to 95％

30

Control Distance

CAT5:  ≤100 meters; Optical Fiber Cable : 500m~15km

31

Control software

LED video (MDK)

32

Control system

Novastar / Linsn / Colorlight

33

Input signal

TV signals ,DVD, DVI, S-VIDEO, RGB, VGA and so on.

34

Maintenance

Back maintenance

35

IP grade

IP65
